2024 aluminum plate is a typical hard aluminum alloy in the aluminum-copper-magnesium system. Its composition is relatively reasonable and its comprehensive performance is good. It is the alloy with the largest amount of hard aluminum. The main alloy component copper makes it easy to corrode. Many items in this alloy have a cladding surface to protect the underlying material.
Common commercial types of 2024 alloy
UNS A92024, Al2024-O, Alclad 2024-O, AA2024-T3, Al2024-T3, Alclad 2024-T3, UNS A82024, Alclad 2024-T4/T351, Al2024-T4, UNS A82024, Alclad 2024-T851.
Aiboer can produce ASTM B209 2024 T4 aluminum sheet, AMS-QQ-A-250/4 2024 aluminum plate, AMS4037 2024 T351 T3 aluminum sheet, the biggest feature of this alloy is high strength and certain heat resistance, it can be used as 150 Working parts below ℃. This is a great option if you need strong, durable aluminum.
Aiboer - 2024 aluminum sheet product specifications
| Aircraft hardware aluminium alloy | 2024 aluminium sheet and 2024 clad aluminium plate |
| Temper | T4, T42, T3, T351, T451, H112, O, T1, T6, T851 |
| Thickness (mm) | 0.5mm-500mm |
| Dimensions (mm) | 1220*2438mm/1250*2500mm, 1500mm*3000mm/1500mm*3600 |
Aiboer - 2024 aluminium sheet plate stock list
| Alloy/Temper | Thickness (mm) | Width（mm) * Length (mm) |
| 2024 -H112 | 8.0-190 | 1500*3000 |
| 10-260 | 2000*4000 | |
| 280 | 1520*3020 | |
| 2024 - O | 0.8-6.0 | 1500*3000 |
| 0.6-1.0 | 2500*3000 | |
| 2.0-3.0 | 1250*2500 | |
| 2024 - T1 | 10-160 | 1500*3000 |
| 2024 -T351 | 12-16.0 | 1500*3000 |
| 0.5-160 | 1500*3000 | |
| 12-230 | 2000*4000 | |
| 2024 -T6 | 0.8-160 | 1500*3000 |
| 20-80 | 2000*4000 | |
| 2024 -T4 | 0.8-4.0 | 1000*2000 |
| 14-20 | 1520*3020 | |
| 0.5-6.0 | 1250*2500 | |
| 16-200 | 2000*4000 |
2024 aluminium sheet chemical composition
| Chemical Element | Present (%) |
| Silicon | 0.5 |
| Iron | 0.5 |
| Copper | 3.8-4.9 |
| Manganese | 0.3-0.9 |
| Magnesium | 1.2-1.8 |
| Chromium | 0.10 |
| Zinc | 0.25 |
| Titanium | 0.15 |
| Other | 0.15 |
| Aluminium | Balance |
2024 aluminium sheet plate physical properties
| Physical property | Value |
| Tensile strengthMpa | 470 |
| 0.2% yield strength Mpa | 325 |
| Elongation (%) | 10 |
| Fatigue strength | 105 |
| Conductivity 20℃ | 30 |
| 20℃ resistivity nΩ.m | 48 |
| Elastic modulus GPa | 68 |
2024 Aluminum plate hardness HB
| Physical property | Value |
| 2024 H112 aluminum sheet plate HB | 85 |
| 2024 T4 aluminium sheet plate HB | 120~145 |
| 2024 T351 aluminium sheet plate HB | 120~145 |
| 2024 0 aluminium sheet HB | 40 |
2024 Aluminum sheet plate application
2024 T42 aluminum plate is used for bulletproof plate, 2024 T4 military aluminum plate, thickness: 5mm, ballistic limit speed under the impact of 25.4mm diameter spherical steel bullet is 151.7m/s, with good bulletproof performance.
2024 T351 aircraft aluminum sheet is a high-strength aviation aluminum alloy material, T351 surface and internal residual stress, and good explosion impact resistance. It is one of the aviation aluminum alloys. It is widely used in skins, bulkheads and structural parts that need to withstand high cyclic loads on various aircraft.
2024 O/H112 aluminum sheet plates are widely used in molds, precision parts, electronic decoration, hardware, hydraulic equipment, cameras and other fields. The heat treatment strengthening effect is remarkable, but the heat treatment process requires strict requirements, good fatigue resistance, and long service life.
ALclad 2024 T3 aluminum plate is rolled with pure aluminum clad surface, which can improve the corrosion resistance of 2024 aluminum plate.
2024 T652 forged aluminum plate, used for aviation aluminum plate, aluminum flange, customized aviation forged aluminum parts, etc.
2024 aluminium sheet weight
2024 aluminum alloy with a density of 2.85 g/cm3.
Aluminum plate weight calculation: length (mm) x width (m) x density 2.85g/cm3
2024 aluminium sheet price
(LME ingot price + processing fee) * weight + packaging fee + transportation fee
Please contact Aiboer Technology to inquire about the price, and how much is the processing fee per ton for the relevant type of aluminum square rod. The processing fee for 2024 aluminum sheets of different sizes varies greatly, and we will provide you with the best quotation.
In addition to 2024 aluminum plate, Aiboer also produces 2024 T4 aluminum bar, 2024 T652 aluminum forged aluminum plate, 2024 T4 tube, etc.
2024 aluminium plate packing
Packed in export wooden boxes or wooden pallets, fumigated wooden pallets, and provide fumigation certificates.
