6061 aluminum bar rod is a high-strength, corrosion-resistant and easy-to-process aluminum alloy material, which is widely used in aviation, aerospace, automobile and other fields.
Why choose Aiboer Technology's 6061 T4/T6/T651/T451 aluminum bar rod?
Quality could full meet world wide aviation standard.
- AMS 4116 6061-T4 Cold finished bars, rod
- AMS 4115 6061-0 Cold finished bars, rod
- AMS 4117 6061-T6/T651 Cold finished bars, rod
- AMS 4128 6061-T451 Bars Rolled
- QQ-A-200/8 6061-T6/T6511 Extruded bar
- QQ-A-225/8 6061-T6 / T651 Cold finished bar
- EN 3342 6061-T4 Extruded bar
Production and management comply with international aviation quality system certification.
AS9100
OHSAS 18001
ISO14001
ISO 9001
NADCAP HT
NADCAP NDT
IATP16949
Specs of 6061 T4 T6 T651 T451 aluminum bar rod
Alloy | 6061 |
Temper | T4, T6, T451, T651, O |
Out diameter | 3mm-300mm |
Length | 4000mm, 6000mm |
Standard |
AMS 4116 6061-T4 Cold finished bars, rod AMS 4115 6061-0 Cold finished bars, rod AMS 4117 6061-T6/T651 Cold finished bars, rod AMS 4128 6061-T451 Bars Rolled QQ-A-200/8 6061-T6/T6511 Extruded bar QQ-A-225/8 6061-T6 / T651 Cold finished bar EN 3342 6061-T4 Extruded bar |
6061 Aluminum Bar Stock Sizes |
6061 T6 Hexagonal aluminum bar, 12mm-40mm; 6061 T6 Aluminum round bar, diameter from 4mm to 300mm; 6061 T6 aluminum flat bar, A side: from 3mm to 70mm; B side from 10mm to 150mm |
6061 Aluminum Bar Stock Sizes 6061-T6 Hexagonal aluminum bar, 12mm-40mm;
6061T6 Aluminum round bar, diameter from 4mm to 300mm;
6061 T6 aluminum flat bar, A side: from 3mm to 70mm; B side from 10mm to 150mm
Chemical composition of 6061 aluminum alloy
6061 Alloy % | |
Si | 0.40-0.80 |
Fe | 0.70 |
Cu | 0.15-0.40 |
Mn | 0.15 |
Mg | 0.8-1.20 |
Ti | 0.15 |
Al | Remainder |
Mechanical property of 6061 aluminum bar rod
Alloy | Temper | Diameter | Physical Property |
6061 | T4 | 0.125" - 7" (3.175mm - 177.8mm) |
Yield Strength: 34 ksi (235 MPa) Tension Strength: 45 ksi (310 MPa) Elongation: 10% Hardness: 95 HRB |
0 | 0.125" - 7" (3.175mm - 177.8mm) |
Yield Strength: 8 ksi (55 MPa) Tension Strength: 18 ksi (125 MPa) Elongation: 25% Hardness: 65 HB |
|
T6/T651 | 0.125" - 7" (3.175mm - 177.8mm) |
Yield Strength: 45 ksi (310 MPa) Tension Strength: 40 ksi (275 MPa) Elongation: 8% Hardness: 95 HRB |
|
T451 | 0.250" - 12" (6.35mm - 304.8mm) |
Yield Strength: 40 ksi (275 MPa) Tension Strength: 68 ksi (470 MPa) Elongation: 12% Hardness: 120 HB |
Features of 6061 aluminum bar
Excellent mechanical properties: 6061 aluminum bar has high strength, hardness and toughness, which can meet the requirements of high strength and high rigidity.
Good corrosion resistance: 6061 aluminum bar can show good corrosion resistance in most environments, especially in environments containing oxidizing acids, such as nitric acid, sulfuric acid, etc.
Ease of processing: 6061 aluminum bars are easy to process into various shapes, which can meet the production needs of different fields.
Good weldability: 6061 aluminum bar is suitable for most common welding methods, such as argon arc welding, TIG welding, MIG welding, etc.
Excellent electrical and thermal conductivity: 6061 aluminum bar is a good electrical and thermal conductive material, suitable for fields that require heat dissipation and electrical conductivity.
Good surface treatment performance: 6061 aluminum bars can improve surface performance and appearance through various surface treatment methods, such as anodizing, electrophoretic coating, etc.
Types and uses of 6061 aluminum bar
6061 T4 aluminum bar rod is commonly used in the manufacture of parts in fields such as aerospace and automotive, such as aviation components, fuel tanks and pipes, etc.
6061-0 aluminum bar rod is usually used in the manufacture of parts in the fields of structural parts and pipes.
6061-T6/T651 aluminum bar rod is usually used in the manufacture of structural components that require high strength and high rigidity, such as parts in aerospace and automotive fields, such as aircraft wings, frames and wheels.
6061 T4/T451 aluminum bar rod is usually used to manufacture parts that require high strength and high rigidity, such as structural parts and machine parts in the aerospace field.
6061 aluminum square bar is usually square in cross-section, which has a wide range of uses and can be used to manufacture mechanical parts, aerospace devices, etc.
6061 aluminum round bar refers to a circular cross section, which is often used in the manufacture of various mechanical parts, molds, aerospace devices, etc.
6061 aluminum flat bar refers to an aluminum bar with a rectangular or oval cross section, which is usually used to manufacture various mechanical parts, bearings, molds, etc.
Cold drawn 6061 aluminum rod is made by drawing process, which has the characteristics of high strength and good corrosion resistance, and is suitable for manufacturing high-precision parts.
What precautions should be taken when purchasing 6061 aluminum bar?
Specifications and dimensions: It is necessary to determine the required specifications and dimensions, including diameter, length, shape, etc., according to the application occasion and needs.
Material quality: It is necessary to choose 6061 aluminum bars with good quality and suitable composition. You can check the relevant quality inspection reports to ensure that they meet relevant standards.
Production process: Different production processes will affect the performance of aluminum rods, and it is necessary to select the corresponding production process according to the needs, such as extrusion, rolling, cold processing, etc.
Supplier reputation: It is necessary to choose a supplier with reputation and production experience to ensure delivery, quality assurance and other issues.
Packaging and transportation: It is necessary to pay attention to whether the packaging is suitable and whether there is any damage during transportation, so as not to affect the quality and use effect of the aluminum rod.
Price and after-sales service: It is necessary to comprehensively consider price and after-sales service, and choose a supplier with higher cost performance. At the same time, understand the supplier's after-sales service system so that problems can be resolved in time.
